Main Dimensions & Performance Data
| d | 25 mm | Bore diameter |
| DSP | 52 mm | Outside diameter |
| B | 21.5 mm | Width |
| Cur | 335 N | Fatigue load limit, radial |
| B1 | 31 mm | Locking collar total width |
| Cr | 14,020 N | Basic dynamic load rating, radial |
| C0r | 7,880 N | Basic static load rating, radial |
| ≈m | 0.2 kg | Weight |
Dimensions
| C | 15 mm | Width, outer ring |
| S | 7.5 mm | Distance raceway |
| d1 | 34 mm | Rib diameter inner ring |
| Ca | 4.15 mm | Distance to lubrication hole |
| d3 | 38.1 mm | Outside diameter locking collar/locknut |
| W | 3 mm | Width of flats |
Temperature range
| Tmin | -35 °C | Operating temperature min. |
| Tmax | 100 °C | Operating temperature max. |
Calculation factors
| f0 | 13.8 | Calculation factor |
Your current product variant
| Sealing | KRR | Lip seals on both sides |
| Shape of outer surface | B | |
| Manufacturing instruction | FA107 | Bearing with lubrication holes on the locating side |
| Special material | VA | Corrosion-resistant VA design |
