ARCALUB-X.PINION-MD3,0-Z17-B30-G-W
Lubrication gear ARCALUB-X.PINION-MD3,0-Z17-B30-G-W
Thêm vào yêu cầu báo giá
Technical data
Relubrication of tooth sets
Usage
straight teeth
Design
radial
Lubricant feed
open cell PU foam
Material
top
-30 °C ... +140 °C
Operating temperature
5 m/s
Max. permissible circumferential speed at outside diameter
Oil, greases up to NLGI 2
Lubricant
m
3 mm
Modulus
z
17
Teeth number
d
51 mm
Pitch circle diameter
da
57 mm
B
30 mm
L
61.4 mm
≈m
0.4 kg
Weight

Your current product variant
VersionGLubrication gears, straight teeth
