WZ1-1/4-L-CF53
Solid shaft WZ1-1/4-L-CF53
Thêm vào yêu cầu báo giá
Main Dimensions & Performance Data
dLW
31.75 mm
Diameter Shaft
dLWTol
L
Diameter tolerance shaft
LTol
-13 µm
Diameter Shaft tolerance high
LTol
-25 µm
Diameter tolerance low
≈m
6.125 kg/m
Weight

Mounting dimensions
t1
7 µm
Roundness
t2
11 mm
Parallelism 1
SHDmin
1.5 mm
Surface Hardness Depth 2

Your current product variant
Size code1-1/4"
Tolerance diameterLdLW Tol
MaterialCF53Heat treatable steel (material no.:1.1213)
Length5182 mmEWL max.
